Package com.ibm.itim.workflow.model

Provides a model and an applications programming interface for the workflow engine.

See:
Description

Interface Summary

ResourceEntity	Interface for obtaining the assignments of a resource participating in workflow processes.
WorkItem	This interface provides general information about a work item.

Class Summary

Activity	This class provides general information about a workflow actvity.
ActivityEntity	Class that provides management capabilities for an activity in a workflow process
ActivityParticipant	This class is a specialization of workflow participant within the context of a workflow activity.
ActivityResult	This class holds the result of an activity.
Assignment	This class provides general information about an assignment, or work item.
AssignmentEntity	Class that provides management capabilities for an Assignment in a workflow Activity.
AssignmentEventAudit	This defines the class for assignment event audit information
AssignmentGroup	This class provides general information about a group of assignments.
CompleteManualActivityEventAudit	This defines user complete manual activity event audit information
CreateProcessEventAudit	This defines the create process event audit information
DataEventAudit	Class representing an data change event in the workflow engine.
EventAudit	Class representing an auditable event in the workflow engine.
ExecutionEntity	Class that provides management capabilities for an executable object within the workflow engine, such as processes and activities.
ExecutionObject	This class provides general information about an object that is executed by the workflow engine.
HumanResourceEntity	Class representing a human resource participating in workflow processes.
I18NInformationEventAudit	Class representing an auditable information event in the workflow engine.
InformationEventAudit	Class representing an auditable information event in the workflow engine.
InitialProcessContext	Class that holds the intitial context of a workflow process, including the type of the process, the scheduled time of the process, the relevant data to be used as the process runtime context, and other configuable items that define how the process will execute.
PackagedApprovalDecisionItem	This class extends the PackagedApprovalItem class to add information about the decision for a particular item.
PackagedApprovalDocument	This class is used as a workflow relevant data item for activities that require an approval decision on multiple items in one atomic step.
PackagedApprovalItem	This class is used as a component of the PackagedApprovalDocument workflow relevant data item.
Participant	This class provides information about a workflow participant.
ParticipantResolveFailureEventAudit	This defines the class for participant resolve failed event audit information
PasswordPickupEventAudit	This defines user password pickup event audit information
PendingActivity	This class is used to give an aggregate view of a pending manual activity
ProcessManager	Class that provides the interface for creating and querying workflow processes within the workflow engine.
ProcessParticipant	This class is a specialization of workflow participant within the context of a workflow process.
RelevantDataItem	This interface provides general information about a workflow relevant data item.
StateEventAudit	This represents audit information for process and activity state change events.
TimeoutEventAudit	This defines the class for timeout event audit information
WorkflowProcess	This class contains general information about a workflow process.
WorkflowProcessEntity	Class that provides management capabilities for a workflow process.

Enum Summary

PackagedApprovalItem.ItemType

The ItemType enumeration provides the possible object types that could be represented by this approval item.

Exception Summary

WorkflowException

This class is used for errors that occured within the workflow engine.

Package com.ibm.itim.workflow.model Description

Provides a model and an applications programming interface for the workflow engine.

Overview

The Workflow API has been developed to provide the developers of custom extensions to Tivoli Identity Manager a portable and backwards-compatible interface to the workflow environment. This interface is most beneficial when building custom code that can be called from a workflow process as a custom Java application or a JavaScript function (see the JavaScript API for more details). This custom code can then perform special business logic, query external data stores, or even integrate with other workflow engines.

The API consists of a set of java classes that abstract the more commonly used concepts of the workflow environment, such as processes, activities, and relevant data. The classes that make up this API are the same classes the platform uses for its out-of-the-box feature set. A note about security: these classes communicate directly with the workflow engine without authenticating the caller. Clients of this API will be assumed to have an appropriate level of trust. The API is not intended to be used by external un-trusted clients, but to be used within the flow of the provisioning platform’s business logic. It cannot be used remotely or for an external application to iinvoke Tivoli Identity Manager services, and must be used within the platform's runtime environment. The easiest way to deploy client code within the platform’s environment is to have the platform call the code from its published workflow extensions, such as a Java Application activity or a JavaScript activity.

API Description

The Workflow API consists of a set of classes that represent the more commonly used concepts of the workflow environment.

The UML class diagram in Figure 1 below illustrates the primary objects available in the API and their relationships. The primary object is the WorkflowProcess. A WorkflowProcess is parameterized by a set of RelevantDataItems and is implemented by a set of Activities. If an Activity is manual and requires the participation of a Resource, and Assignment is created to represent the task and fulfill the relationship. The most typical type of Resource is the HumanResource. There are several more objects available in the API that are not shown here. See the class level documentation for all classes in this package for a full specification.

Figure 1 - Primary Workflow Class Diagram

There is a consistent framework implemented in this API for querying and operating on workflow objects. This framework is centered on an entity class. An entity class is a composite class that holds a reference to a value class that holds the defining attribute information for the entity, and provides access to other related entities. The attribute information is cached for the life of the entity, however, every time a relationship is evaluated, the entity, or entities, that participate in that relationship will be loaded from the data store. For example, the name of a workflow process is cached within the WorkflowProcess entity class, but when the client requests the activities of the process, the activities will be retrieved from the data store and represented as Activity entities.

API Example

The following method uses the Workflow API to print the audit trail of a specified process. It organizes the audit trail by activity.

public static void printAuditTrail(long processId) {

    try {

        // Retrieve the process information

        WorkflowProcessEntity process = new ProcessManager().getProcess(processId);


        // Retrieve activities

        Collection activities = process.getActivities();

        Iterator iter = activities.iterator();

        // Iterate over all activities and obtain audit trail

        while (iter.hasNext()) {

            ActivityEntity activity = (ActivityEntity)iter.next();

            System.out.println(activity.getValueObject().getDesignId());

            List auditTrail = activity.getHistory();

            Iterator auditIter = auditTrail.iterator();

            // Iterate over all audit records and print

            while (iter.hasNext()) {

                EventAudit record = (EventAudit)iter.next();

                System.out.println(record.getTimeStamp + ": " + record.getEventType());

            }

            System.out.println();

        }

    } catch (WorkflowException we) {

        System.err.println("Workflow Exception: " + we.toString());

    }

}
